IM02SHR22H

IM02SHR22H

Image is for reference,
please contact us to get the real picture

Part No :

IM02SHR22H

Manufacturer
Vishay / Dale
Description
FIXED IND 220NH 1.025A 140 MOHM
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Oct 12 - Oct 16 2025
DataSheet
IM02SHR22H PDF
Availability
0 pieces
Unit Price
$0.00000

Current price of IM02SHR22H is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

IM02SHR22H Specifications
Type Description
Series:IM
Package:-
Part Status:Obsolete
Type:Molded
Material - Core:Phenolic
Inductance:220 nH
Tolerance:±3%
Current Rating (Amps):1.025 A
Current - Saturation (Isat):-
Shielding:Unshielded
DC Resistance (DCR):140mOhm Max
Q @ Freq:33 @ 25MHz
Frequency - Self Resonant:510MHz
Ratings:-
Operating Temperature:-55°C ~ 125°C
Inductance Frequency - Test:25 MHz
Features:-
Mounting Type:Through Hole
Package / Case:Axial
Supplier Device Package:-
Size / Dimension:0.095" Dia x 0.250" L (2.42mm x 6.35mm)
Height - Seated (Max):-
