NB2309AI1HDTG

Part No :: NB2309AI1HDTG

Manufacturer: VIGOR

VIGOR # :: 3871605

Description: PLL CLOCK DRIVER

Catalog: Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers

DataSheet: NB2309AI1HDTG PDF

Country of origin: -

Date code: -

NB2309AI1HDTG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Type:	Zero Delay Buffer
PLL:	Yes with Bypass
Input:	Clock
Output:	Clock
Number of Circuits:	1
Ratio - Input:Output:	1:9
Differential - Input:Output:	No/No
Frequency - Max:	133.33MHz
Divider/Multiplier:	No/No
Voltage - Supply:	3V ~ 3.6V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	16-TSSOP
