NB3N2302DG

Part No :: NB3N2302DG

Manufacturer: VIGOR

VIGOR # :: 3874763

Description: AND/NAND GATE, 10EL SERIES, 1 FU

Catalog: Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers

DataSheet: NB3N2302DG PDF

Country of origin: -

Date code: -

NB3N2302DG Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Type:	Clock Multiplier, Zero Delay Buffer
PLL:	Yes
Input:	LVCMOS, LVTTL
Output:	LVCMOS, LVTTL
Number of Circuits:	1
Ratio - Input:Output:	1:2
Differential - Input:Output:	No/No
Frequency - Max:	133MHz
Divider/Multiplier:	No/Yes
Voltage - Supply:	3.135V ~ 3.465V, 4.5V ~ 5.5V
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
