DS1100Z-45

Part No :: DS1100Z-45

Manufacturer: VIGOR

VIGOR # :: 3686639

Description: DS1100 5-TAP (DELAY LINE)

Catalog: Clock/Timing - Delay Lines

DataSheet: DS1100Z-45 PDF

Country of origin: -

Date code: -

DS1100Z-45 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Number of Taps/Steps:	5
Function:	Nonprogrammable
Delay to 1st Tap:	9ns
Tap Increment:	9 ns
Available Total Delays:	45ns
Number of Independent Delays:	1
Voltage - Supply:	4.75V ~ 5.25V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
DS1100Z-45+T Match 100%	VIGOR DS1100 5-TAP ECONOMY TIMING ELEM	DS1100Z-45 vs DS1100Z-45+T
DS1100LZ-45+T Match 100%	Maxim Integrated IC DELAY LINE 5TAP 45NS 8SOIC	DS1100Z-45 vs DS1100LZ-45+T
DS1100LZ-45+ Match 100%	Maxim Integrated IC DELAY LINE 5TAP 45NS 8SOIC	DS1100Z-45 vs DS1100LZ-45+
DS1100LZ-45 Match 100%	VIGOR DS1100 5-TAP (DELAY LINE)	DS1100Z-45 vs DS1100LZ-45
DS1100Z-45/T&R Match 100%	Maxim Integrated IC DELAY LINE 5TAP 45NS 8SOIC	DS1100Z-45 vs DS1100Z-45/T&R
