DS1004Z-3+T

Part No :: DS1004Z-3+T

Manufacturer: VIGOR

VIGOR # :: 3686936

Description: 5-TAP HIGH SPEED DELAY LINE

Catalog: Clock/Timing - Delay Lines

DataSheet: DS1004Z-3+T PDF

Country of origin: -

Date code: -

DS1004Z-3+T Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Number of Taps/Steps:	5
Function:	Nonprogrammable
Delay to 1st Tap:	5ns
Tap Increment:	3 ns
Available Total Delays:	17ns
Number of Independent Delays:	1
Voltage - Supply:	4.75V ~ 5.25V
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
DS1004Z-3 Match 100%	VIGOR 5-TAP HIGH SPEED DELAY LINE	DS1004Z-3+T vs DS1004Z-3
DS1004Z-3+ Match 100%	Maxim Integrated IC DELAY LINE 5TAP 17NS 8SOIC	DS1004Z-3+T vs DS1004Z-3+
DS1004Z-3/T&R Match 100%	Maxim Integrated IC DELAY LINE 5TAP 17NS 8SOIC	DS1004Z-3+T vs DS1004Z-3/T&R
