DS1005S-75/T&R

Part No :: DS1005S-75/T&R

Manufacturer: Maxim Integrated

VIGOR # :: 4817254

Description: IC DELAY LINE 5TAP 75NS 16SOIC

Catalog: Clock/Timing - Delay Lines

DataSheet: DS1005S-75/T&R PDF

Country of origin: -

Date code: -

DS1005S-75/T&R Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Number of Taps/Steps:	5
Function:	Nonprogrammable
Delay to 1st Tap:	15ns
Tap Increment:	15 ns
Available Total Delays:	75ns
Number of Independent Delays:	1
Voltage - Supply:	4.75V ~ 5.25V
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
