DS1689S

Part No :: DS1689S

Manufacturer: Maxim Integrated

VIGOR # :: 4839582

Description: IC RTC CLK/CALENDAR PAR 28-SOIC

Catalog: Clock/Timing - Real Time Clocks

DataSheet: DS1689S PDF

Country of origin: -

Date code: -

DS1689S Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Type:	Clock/Calendar
Features:	NVSRAM
Memory Size:	114B
Time Format:	HH:MM:SS (12/24 hr)
Date Format:	YY-MM-DD-dd
Interface:	Parallel
Voltage - Supply:	2.7V ~ 3.3V, 4.5V ~ 5.5V
Voltage - Supply, Battery:	2.5V ~ 3.7V
Current - Timekeeping (Max):	2mA @ 3V, 3mA @ 5V
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Package / Case:	28-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	28-SOIC
