AD7685BCPZRL7

Part No :: AD7685BCPZRL7

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3778938

Description: IC ADC 16BIT SAR 10LFCSP-WD

Catalog: Data Acquisition - Analog to Digital Converters (ADC)

DataSheet: AD7685BCPZRL7 PDF

Country of origin: -

Date code: -

AD7685BCPZRL7 Specifications

Type	Description
Series:	PulSAR®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Bits:	16
Sampling Rate (Per Second):	250k
Number of Inputs:	1
Input Type:	Pseudo-Differential
Data Interface:	SPI, DSP
Configuration:	S/H-ADC
Ratio - S/H:ADC:	1:1
Number of A/D Converters:	1
Architecture:	SAR
Reference Type:	External
Voltage - Supply, Analog:	2.3V ~ 5.5V
Voltage - Supply, Digital:	2.3V ~ 5.5V
Features:	-
Operating Temperature:	-40°C ~ 85°C
Package / Case:	10-VFDFN Exposed Pad, CSP
Supplier Device Package:	10-LFCSP-WD (3x3)
Mounting Type:	Surface Mount
