DS1809Z-100

Part No :: DS1809Z-100

Manufacturer: VIGOR

VIGOR # :: 3860813

Description: DS1809 DALLASTAT

Catalog: Data Acquisition - Digital Potentiometers

DataSheet: DS1809Z-100 PDF

Country of origin: -

Date code: -

DS1809Z-100 Specifications

Type	Description
Series:	Dallastat™
Package:	Tube
Part Status:	Obsolete
Taper:	Linear
Configuration:	Potentiometer
Number of Circuits:	1
Number of Taps:	64
Resistance (Ohms):	100k
Interface:	Pushbutton
Memory Type:	Non-Volatile
Voltage - Supply:	5V
Features:	-
Tolerance:	±20%
Temperature Coefficient (Typ):	750ppm/°C
Mounting Type:	Surface Mount
Supplier Device Package:	8-SOIC
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Operating Temperature:	-40°C ~ 85°C
Resistance - Wiper (Ohms) (Typ):	400 (Max)
