MAX5156AEEE+

Part No :: MAX5156AEEE+

Manufacturer: Maxim Integrated

VIGOR # :: 3790920

Description: IC DAC 12BIT V-OUT 16QSOP

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: MAX5156AEEE+ PDF

Country of origin: -

Date code: -

MAX5156AEEE+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Number of Bits:	12
Number of D/A Converters:	2
Settling Time:	15µs (Typ)
Output Type:	Voltage - Buffered
Differential Output:	No
Data Interface:	SPI
Reference Type:	External
Voltage - Supply, Analog:	5V
Voltage - Supply, Digital:	5V
INL/DNL (LSB):	±0.5 (Max), ±1 (Max)
Architecture:	R-2R
Operating Temperature:	-40°C ~ 85°C
Package / Case:	16-SSOP (0.154", 3.90mm Width)
Supplier Device Package:	16-QSOP
Mounting Type:	Surface Mount
