AD7543BQ

Part No :: AD7543BQ

Manufacturer: VIGOR

VIGOR # :: 3792709

Description: DAC, SERIAL INPUT LOADING

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: AD7543BQ PDF

Country of origin: -

Date code: -

AD7543BQ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Number of Bits:	12
Number of D/A Converters:	1
Settling Time:	2µs
Output Type:	Current - Unbuffered
Differential Output:	Yes
Data Interface:	Serial
Reference Type:	External
Voltage - Supply, Analog:	5V
Voltage - Supply, Digital:	5V
INL/DNL (LSB):	±0.5 (Max), ±1 (Max)
Architecture:	R-2R
Operating Temperature:	-40°C ~ 85°C
Package / Case:	16-CDIP (0.300", 7.62mm)
Supplier Device Package:	16-CDIP
Mounting Type:	Through Hole

Alternative Products

Part Number	Manufacturer & Description	Compare
AD7542GBQ Match 100%	VIGOR DAC, 1 FUNC, PARALLEL, 4 BITS IN	AD7543BQ vs AD7542GBQ
AD7542BQ Match 100%	Linear Technology (Analog Devices, Inc.) IC DAC 12BIT A-OUT 16CDIP	AD7543BQ vs AD7542BQ
