MAX536ACPE

Part No :: MAX536ACPE

Manufacturer: VIGOR

VIGOR # :: 3792993

Description: QUAD, 12-BIT VOLTAGE-OUT DAC

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: MAX536ACPE PDF

Country of origin: -

Date code: -

MAX536ACPE Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Number of Bits:	12
Number of D/A Converters:	4
Settling Time:	3µs (Typ)
Output Type:	Voltage - Buffered
Differential Output:	No
Data Interface:	SPI
Reference Type:	External
Voltage - Supply, Analog:	10.8V ~ 13.2V, -5V
Voltage - Supply, Digital:	-
INL/DNL (LSB):	±0.15, ±1 (Max)
Architecture:	R-2R
Operating Temperature:	0°C ~ 70°C
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
Mounting Type:	Through Hole
