MAX5801ATB+

Part No :: MAX5801ATB+

Manufacturer: Maxim Integrated

VIGOR # :: 4879367

Description: IC DAC 10BIT V-OUT 10TDFN

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: MAX5801ATB+ PDF

Country of origin: -

Date code: -

MAX5801ATB+ Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Number of Bits:	10
Number of D/A Converters:	2
Settling Time:	2.6µs (Typ)
Output Type:	Voltage - Buffered
Differential Output:	No
Data Interface:	I²C
Reference Type:	External, Internal
Voltage - Supply, Analog:	2.7V ~ 5.5V
Voltage - Supply, Digital:	2.7V ~ 5.5V
INL/DNL (LSB):	±0.25, ±0.1
Architecture:	R-2R
Operating Temperature:	-40°C ~ 125°C
Package / Case:	10-WFDFN Exposed Pad
Supplier Device Package:	10-TDFN-EP (3x3)
Mounting Type:	Surface Mount
