DAC8420ES-REEL

Part No :: DAC8420ES-REEL

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 4879586

Description: IC DAC 12BIT V-OUT 16SOIC

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: DAC8420ES-REEL PDF

Country of origin: -

Date code: -

DAC8420ES-REEL Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Number of Bits:	12
Number of D/A Converters:	4
Settling Time:	13µs (Typ)
Output Type:	Voltage - Buffered
Differential Output:	No
Data Interface:	SPI
Reference Type:	External
Voltage - Supply, Analog:	5V ~ 15V, -15V
Voltage - Supply, Digital:	5V
INL/DNL (LSB):	±0.5, ±0.25
Architecture:	R-2R
Operating Temperature:	-40°C ~ 85°C
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
Mounting Type:	Surface Mount
