CY8CLED03D02-56LTXI

Part No :: CY8CLED03D02-56LTXI

Manufacturer: Cypress Semiconductor

VIGOR # :: 4934567

Description: IC MCU 8BIT 16KB FLASH 56VQFN

Catalog: Embedded - Microcontrollers - Application Specific

DataSheet: CY8CLED03D02-56LTXI PDF

Country of origin: -

Date code: -

CY8CLED03D02-56LTXI Specifications

Type	Description
Series:	PowerPSoC® CY8CLED
Package:	Tray
Part Status:	Obsolete
Applications:	Intelligent LED Driver
Core Processor:	M8C
Program Memory Type:	FLASH (16KB)
Controller Series:	CY8CLED
RAM Size:	1K x 8
Interface:	DALI, DMX512, I²C, IrDA, SPI, UART/USART
Number of I/O:	14
Voltage - Supply:	4.75V ~ 5.25V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	56-VFQFN Exposed Pad
Supplier Device Package:	56-QFN (8x8)

Alternative Products

Part Number	Manufacturer & Description	Compare
CY8CLED03G01-56LTXI Match 100%	VIGOR LED DRIVER, 3-SEGMENT, CMOS	CY8CLED03D02-56LTXI vs CY8CLED03G01-56LTXI
CY8CLED04D02-56LTXI Match 100%	VIGOR LED DRIVER, 4-SEGMENT, CMOS	CY8CLED03D02-56LTXI vs CY8CLED04D02-56LTXI
CY8CLED03D01-56LTXI Match 100%	VIGOR LED DRIVER, 3-SEGMENT, CMOS	CY8CLED03D02-56LTXI vs CY8CLED03D01-56LTXI
CY8CLED01D01-56LTXI Match 100%	VIGOR LED DRIVER, 1-SEGMENT, CMOS	CY8CLED03D02-56LTXI vs CY8CLED01D01-56LTXI
CY8CLED04G01-56LTXI Match 100%	VIGOR LED DRIVER, 4-SEGMENT, CMOS	CY8CLED03D02-56LTXI vs CY8CLED04G01-56LTXI
CY8CLED02D01-56LTXI Match 100%	Cypress Semiconductor IC MCU 8BIT 16KB FLASH 56VQFN	CY8CLED03D02-56LTXI vs CY8CLED02D01-56LTXI
