MAX314FEPE+

Part No :: MAX314FEPE+

Manufacturer: VIGOR

VIGOR # :: 3924578

Description: SPST ANALOG SWITCH

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MAX314FEPE+ PDF

Country of origin: -

Date code: -

MAX314FEPE+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SPST - NO/NC
Multiplexer/Demultiplexer Circuit:	1:1
Number of Circuits:	4
On-State Resistance (Max):	10Ohm
Channel-to-Channel Matching (ΔRon):	50mOhm
Voltage - Supply, Single (V+):	9V ~ 36V
Voltage - Supply, Dual (V±):	±4.5V ~ 20V
Switch Time (Ton, Toff) (Max):	225ns, 185ns
-3db Bandwidth:	-
Charge Injection:	70pC
Channel Capacitance (CS(off), CD(off)):	20pF, 20pF
Current - Leakage (IS(off)) (Max):	1nA
Crosstalk:	-104dB @ 1MHz
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
