ADG509FBRN

Part No :: ADG509FBRN

Manufacturer: VIGOR

VIGOR # :: 3924955

Description: DUAL DIFFERENTIAL 4:1 MUX

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG509FBRN PDF

Country of origin: -

Date code: -

ADG509FBRN Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	270Ohm (Typ)
Channel-to-Channel Matching (ΔRon):	8.1Ohm
Voltage - Supply, Single (V+):	15V
Voltage - Supply, Dual (V±):	±15V
Switch Time (Ton, Toff) (Max):	230ns, 130ns
-3db Bandwidth:	-
Charge Injection:	15pC
Channel Capacitance (CS(off), CD(off)):	3pF, 12pF
Current - Leakage (IS(off)) (Max):	1nA
Crosstalk:	-
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
