ADG509AKPZ

Part No :: ADG509AKPZ

Manufacturer: VIGOR

VIGOR # :: 3926081

Description: DIFFERENTIAL MUX,4 CHANNEL

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG509AKPZ PDF

Country of origin: -

Date code: -

ADG509AKPZ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	450Ohm
Channel-to-Channel Matching (ΔRon):	22.5Ohm
Voltage - Supply, Single (V+):	10.8V ~ 16.5V
Voltage - Supply, Dual (V±):	±10.8V ~ 16.5V
Switch Time (Ton, Toff) (Max):	300ns, 300ns
-3db Bandwidth:	-
Charge Injection:	4pC
Channel Capacitance (CS(off), CD(off)):	5pF, 11pF
Current - Leakage (IS(off)) (Max):	1nA
Crosstalk:	-
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-LCC (J-Lead)
Supplier Device Package:	20-PLCC (9x9)
