ADG1309BRZ-REEL7

Part No :: ADG1309BRZ-REEL7

Manufacturer: VIGOR

VIGOR # :: 3926227

Description: DIFFERENTIAL MULTIPLEXER, 4 CHAN

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG1309BRZ-REEL7 PDF

Country of origin: -

Date code: -

ADG1309BRZ-REEL7 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	210Ohm
Channel-to-Channel Matching (ΔRon):	5Ohm
Voltage - Supply, Single (V+):	5V ~ 16.5V
Voltage - Supply, Dual (V±):	±5V ~ 16.5V
Switch Time (Ton, Toff) (Max):	100ns, 100ns
-3db Bandwidth:	500MHz
Charge Injection:	2pC
Channel Capacitance (CS(off), CD(off)):	10pF, 15pF
Current - Leakage (IS(off)) (Max):	1nA
Crosstalk:	-80dB @ 1MHz
Operating Temperature:	-40°C ~ 105°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
