ADG1209YRZ-REEL7

Part No :: ADG1209YRZ-REEL7

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3926536

Description: IC MULTIPLEXER DUAL 4X1 16SOIC

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG1209YRZ-REEL7 PDF

Country of origin: -

Date code: -

ADG1209YRZ-REEL7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	200Ohm
Channel-to-Channel Matching (ΔRon):	3.5Ohm
Voltage - Supply, Single (V+):	5V ~ 16.5V
Voltage - Supply, Dual (V±):	±5V ~ 16.5V
Switch Time (Ton, Toff) (Max):	95ns, 100ns
-3db Bandwidth:	550MHz
Charge Injection:	0.4pC
Channel Capacitance (CS(off), CD(off)):	1.5pF, 4.5pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-85dB @ 1MHz
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
ADGS1208BCPZ-RL7 Match 100%	Linear Technology (Analog Devices, Inc.) IC SWITCH SINGLE 24LFCSP	ADG1209YRZ-REEL7 vs ADGS1208BCPZ-RL7
ADG1208YCPZ-REEL7 Match 100%	Linear Technology (Analog Devices, Inc.) IC MULTIPLEXER 8X1 16LFCSP	ADG1209YRZ-REEL7 vs ADG1208YCPZ-REEL7
ADG1208YRZ Match 100%	Linear Technology (Analog Devices, Inc.) IC MULTIPLEXER 8X1 16SOIC	ADG1209YRZ-REEL7 vs ADG1208YRZ
ADG1208YCPZ-REEL Match 100%	Linear Technology (Analog Devices, Inc.) IC MULTIPLEXER 8X1 16LFCSP	ADG1209YRZ-REEL7 vs ADG1208YCPZ-REEL
ADG1209YRZ Match 100%	Linear Technology (Analog Devices, Inc.) IC MULTIPLEXER DUAL 4X1 16SOIC	ADG1209YRZ-REEL7 vs ADG1209YRZ
ADG1208YRUZ-REEL7 Match 100%	Linear Technology (Analog Devices, Inc.) IC MULTIPLEXER 8X1 16TSSOP	ADG1209YRZ-REEL7 vs ADG1208YRUZ-REEL7

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 5360

Shipped from

HK warehouse

Expected Shipping Date

Jul 28 - Aug 01 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$6.1900~~	~~$6.19~~
1000	~~$3.5451~~	~~$3 545.10~~

Current price of ADG1209YRZ-REEL7 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com

Hot Products

74LVC2G53DP,125

IC MUX/DEMUX 2X1 8TSSOP

DG304ACWE+

IC ANALOG SWITCH CMOS 16SOIC

MAX320ESA+
