ADG1609BCPZ-REEL7

Part No :: ADG1609BCPZ-REEL7

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3927146

Description: IC MULTIPLEXER DL 4X1 16LFCSP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG1609BCPZ-REEL7 PDF

Country of origin: -

Date code: -

ADG1609BCPZ-REEL7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	4.5Ohm
Channel-to-Channel Matching (ΔRon):	120mOhm
Voltage - Supply, Single (V+):	3.3V ~ 16V
Voltage - Supply, Dual (V±):	±3.3V ~ 8V
Switch Time (Ton, Toff) (Max):	94ns, 93ns
-3db Bandwidth:	78MHz
Charge Injection:	29pC
Channel Capacitance (CS(off), CD(off)):	19pF, 59pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-64dB @ 1MHz
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-WFQFN Exposed Pad, CSP
Supplier Device Package:	16-LFCSP-WQ (3x3)
