ADG713BR

Part No :: ADG713BR

Manufacturer: VIGOR

VIGOR # :: 3927301

Description: QUAD SPST SWITCH

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG713BR PDF

Country of origin: -

Date code: -

ADG713BR Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SPST - NO/NC
Multiplexer/Demultiplexer Circuit:	1:1
Number of Circuits:	4
On-State Resistance (Max):	4Ohm
Channel-to-Channel Matching (ΔRon):	-
Voltage - Supply, Single (V+):	1.8V ~ 5.5V
Voltage - Supply, Dual (V±):	-
Switch Time (Ton, Toff) (Max):	11ns, 6ns (Typ)
-3db Bandwidth:	200MHz
Charge Injection:	3pC
Channel Capacitance (CS(off), CD(off)):	10pF, 10pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-90dB @ 10MHz
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
