ADG1236YCPZ-500RL7

Part No :: ADG1236YCPZ-500RL7

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3927845

Description: IC SWITCH DUAL SPDT 12LFCSP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG1236YCPZ-500RL7 PDF

Country of origin: -

Date code: -

ADG1236YCPZ-500RL7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Switch Circuit:	SPDT
Multiplexer/Demultiplexer Circuit:	2:1
Number of Circuits:	2
On-State Resistance (Max):	190Ohm
Channel-to-Channel Matching (ΔRon):	3.5Ohm
Voltage - Supply, Single (V+):	12V
Voltage - Supply, Dual (V±):	±15V
Switch Time (Ton, Toff) (Max):	150ns, 90ns
-3db Bandwidth:	1GHz
Charge Injection:	-1pC
Channel Capacitance (CS(off), CD(off)):	1.6pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-85dB @ 1MHz
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	12-WFQFN Exposed Pad, CSP
Supplier Device Package:	12-LFCSP-WQ (3x3)
