ADG511BNZ

Part No :: ADG511BNZ

Manufacturer: VIGOR

VIGOR # :: 3928130

Description: QUAD SPST SWITCH

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG511BNZ PDF

Country of origin: -

Date code: -

ADG511BNZ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SPST - NC
Multiplexer/Demultiplexer Circuit:	1:1
Number of Circuits:	4
On-State Resistance (Max):	30Ohm (Typ)
Channel-to-Channel Matching (ΔRon):	-
Voltage - Supply, Single (V+):	3V ~ 5.5V
Voltage - Supply, Dual (V±):	±4.5V ~ 5.5V
Switch Time (Ton, Toff) (Max):	200ns, 120ns (Typ)
-3db Bandwidth:	-
Charge Injection:	11pC
Channel Capacitance (CS(off), CD(off)):	9pF, 9pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-85dB @ 1MHz
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
