ADG5204BRUZ

Part No :: ADG5204BRUZ

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3928435

Description: IC MUX 4:1 170 OHM 14TSSOP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG5204BRUZ PDF

Country of origin: -

Date code: -

ADG5204BRUZ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	1
On-State Resistance (Max):	160Ohm
Channel-to-Channel Matching (ΔRon):	4.5Ohm
Voltage - Supply, Single (V+):	9V ~ 40V
Voltage - Supply, Dual (V±):	±9V ~ 22V
Switch Time (Ton, Toff) (Max):	185ns, 175ns
-3db Bandwidth:	150MHz
Charge Injection:	-0.6pC
Channel Capacitance (CS(off), CD(off)):	3pF, 26pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-80dB @ 1MHz
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	14-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	14-TSSOP
