MAX4615ESD

Part No :: MAX4615ESD

Manufacturer: VIGOR

VIGOR # :: 3929673

Description: QUAD, SPST CMOS ANALOG SWITCH

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MAX4615ESD PDF

Country of origin: -

Date code: -

MAX4615ESD Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SPST - NC
Multiplexer/Demultiplexer Circuit:	1:1
Number of Circuits:	4
On-State Resistance (Max):	10Ohm
Channel-to-Channel Matching (ΔRon):	200mOhm
Voltage - Supply, Single (V+):	2V ~ 5.5V
Voltage - Supply, Dual (V±):	-
Switch Time (Ton, Toff) (Max):	12ns, 10ns
-3db Bandwidth:	70MHz
Charge Injection:	6.5pC
Channel Capacitance (CS(off), CD(off)):	5pF, 5pF
Current - Leakage (IS(off)) (Max):	1nA
Crosstalk:	-96dB @ 100kHz
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	14-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	14-SOIC
