MAX4534CSD+

Part No :: MAX4534CSD+

Manufacturer: Maxim Integrated

VIGOR # :: 3929700

Description: IC MULTIPLEXER 4X1 14SOIC

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MAX4534CSD+ PDF

Country of origin: -

Date code: -

MAX4534CSD+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	1
On-State Resistance (Max):	400Ohm
Channel-to-Channel Matching (ΔRon):	2Ohm
Voltage - Supply, Single (V+):	9V ~ 36V
Voltage - Supply, Dual (V±):	±4.5V ~ 20V
Switch Time (Ton, Toff) (Max):	275ns, 200ns
-3db Bandwidth:	-
Charge Injection:	1pC
Channel Capacitance (CS(off), CD(off)):	5pF, 6.5pF
Current - Leakage (IS(off)) (Max):	500pA
Crosstalk:	-53dB @ 1MHz
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	14-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	14-SOIC
