MAX4536CSE

Part No :: MAX4536CSE

Manufacturer: VIGOR

VIGOR # :: 3930422

Description: QUAD SPST ANALOG SWITCH

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MAX4536CSE PDF

Current price of MAX4536CSE is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MAX4536CSE Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SPST - NO
Multiplexer/Demultiplexer Circuit:	1:1
Number of Circuits:	4
On-State Resistance (Max):	100Ohm
Channel-to-Channel Matching (ΔRon):	1Ohm
Voltage - Supply, Single (V+):	2V ~ 12V
Voltage - Supply, Dual (V±):	±2V ~ 6V
Switch Time (Ton, Toff) (Max):	100ns, 50ns
-3db Bandwidth:	-
Charge Injection:	1pC
Channel Capacitance (CS(off), CD(off)):	2pF, 2pF
Current - Leakage (IS(off)) (Max):	2nA
Crosstalk:	-75dB @ 1MHz
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
