MAX4509CPE

Part No :: MAX4509CPE

Manufacturer: Maxim Integrated

VIGOR # :: 4921283

Description: IC MUX 8CH DUAL 4CH 16DIP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MAX4509CPE PDF

Country of origin: -

Date code: -

MAX4509CPE Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SP4T
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	400Ohm
Channel-to-Channel Matching (ΔRon):	15Ohm (Max)
Voltage - Supply, Single (V+):	9V ~ 36V
Voltage - Supply, Dual (V±):	±4.5V ~ 20V
Switch Time (Ton, Toff) (Max):	275ns, 200ns
-3db Bandwidth:	-
Charge Injection:	2pC
Channel Capacitance (CS(off), CD(off)):	10pF, 14pF
Current - Leakage (IS(off)) (Max):	500pA
Crosstalk:	-62dB @ 1MHz
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
