ADG783BCPZ-REEL

Part No :: ADG783BCPZ-REEL

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 4921459

Description: IC SWITCH QUAD SPST 20LFCSP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG783BCPZ-REEL PDF

Country of origin: -

Date code: -

ADG783BCPZ-REEL Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Switch Circuit:	SPST - NO/NC
Multiplexer/Demultiplexer Circuit:	1:1
Number of Circuits:	4
On-State Resistance (Max):	4Ohm
Channel-to-Channel Matching (ΔRon):	-
Voltage - Supply, Single (V+):	1.8V ~ 5.5V
Voltage - Supply, Dual (V±):	-
Switch Time (Ton, Toff) (Max):	11ns, 6ns (Typ)
-3db Bandwidth:	200MHz
Charge Injection:	3pC
Channel Capacitance (CS(off), CD(off)):	10pF, 10pF
Current - Leakage (IS(off)) (Max):	100pA
Crosstalk:	-90dB @ 10MHz
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-WFQFN Exposed Pad, CSP
Supplier Device Package:	20-LFCSP-WQ (4x4)
