MC14052BDTR2

Part No :: MC14052BDTR2

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4921779

Description: IC MUX/DEMUX DUAL 4X1 16TSSOP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MC14052BDTR2 PDF

Country of origin: -

Date code: -

MC14052BDTR2 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Switch Circuit:	DP4T
Multiplexer/Demultiplexer Circuit:	2:4
Number of Circuits:	2
On-State Resistance (Max):	280Ohm
Channel-to-Channel Matching (ΔRon):	10Ohm
Voltage - Supply, Single (V+):	3V ~ 18V
Voltage - Supply, Dual (V±):	-
Switch Time (Ton, Toff) (Max):	-
-3db Bandwidth:	17MHz
Charge Injection:	-
Channel Capacitance (CS(off), CD(off)):	7.5pF
Current - Leakage (IS(off)) (Max):	100nA
Crosstalk:	-
Operating Temperature:	-55°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	16-TSSOP
