DS2109S

Part No :: DS2109S

Manufacturer: Maxim Integrated

VIGOR # :: 4786178

Description: IC TERM SCSI PLUG/PLAY 28-SOIC

Catalog: Interface - Signal Terminators

DataSheet: DS2109S PDF

Country of origin: -

Date code: -

DS2109S Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Type:	SCSI
Number of Terminations:	18
Voltage - Supply:	4V ~ 5.25V
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Package / Case:	28-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	28-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
UC5602DWP Match 100%	VIGOR SCSI TERMINATOR, 18-LINE, 110OHM	DS2109S vs UC5602DWP
UCC5618DWPTRG4 Match 100%	Texas Instruments IC SCSI 18-LINE TERM 28-SOIC	DS2109S vs UCC5618DWPTRG4
UCC5617DWPG4 Match 100%	Texas Instruments IC SCSI 18-LINE TERM 28-SOIC	DS2109S vs UCC5617DWPG4
UC5601DWPG4 Match 100%	Texas Instruments IC TERMINATOR SCSI 28SOIC	DS2109S vs UC5601DWPG4
UCC5618DWPG4 Match 100%	Texas Instruments IC SCSI 18-LINE TERM 28-SOIC	DS2109S vs UCC5618DWPG4
UC5601DWPTRG4 Match 100%	Texas Instruments IC TERMINATOR SCSI 28SOIC	DS2109S vs UC5601DWPTRG4
