ISD5104EYR

Part No :: ISD5104EYR

Manufacturer: Nuvoton Technology Corporation America

Description: IC VOICE REC/PLAY 4MN 22S 28TSOP

Catalog: Interface - Voice Record and Playback

DataSheet: ISD5104EYR PDF

Availability: 707 pieces

Current price of ISD5104EYR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ISD5104EYR Specifications

Type	Description
Series:	ChipCorder®
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Interface:	I²C
Input Signal:	Analog - Single Ended, Microphone
Output Signal:	Analog - Single Ended, Analog Differential, PWM Speaker Output
Sampling Frequency:	4 ~ 8kHz
Duration:	2 Min 11 Sec ~ 4 Min 22 Sec
Filter Pass Band:	1.7 ~ 3.4kHz
Messaging:	Multiple
Oscillator Type:	Internal/External
Features:	Auto Mute, Automatic Gain Control, Digital Data Storage, Volume Control
Operating Temperature:	0°C ~ 70°C (TA)
Voltage - Supply:	2.7 V ~ 3.3 V
Mounting Type:	Surface Mount
Package / Case:	28-TSSOP (0.465", 11.80mm Width)
Supplier Device Package:	28-TSOP
