DM74S20N

Part No :: DM74S20N

Manufacturer: VIGOR

VIGOR # :: 3813070

Description: IC GATE NAND 2CH 4-INP 14DIP

Catalog: Logic - Gates and Inverters

DataSheet: DM74S20N PDF

Country of origin: -

Date code: -

DM74S20N Specifications

Type	Description
Series:	74S
Package:	Tube
Part Status:	Obsolete
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	4.75V ~ 5.25V
Current - Quiescent (Max):	-
Current - Output High, Low:	1mA, 20mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	8ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Through Hole
Supplier Device Package:	14-PDIP
Package / Case:	14-DIP (0.300", 7.62mm)
