SN74LVC2G00YZPR

Part No :: SN74LVC2G00YZPR

Manufacturer: Texas Instruments

Description: IC GATE NAND 2CH 2-INP 8DSBGA

Catalog: Logic - Gates and Inverters

DataSheet: SN74LVC2G00YZPR PDF

Availability: 3473 pieces

Unit Price: ~~$0.26000~~

Current price of SN74LVC2G00YZPR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SN74LVC2G00YZPR Specifications

Type	Description
Series:	74LVC
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	2
Features:	-
Voltage - Supply:	1.65V ~ 5.5V
Current - Quiescent (Max):	10 µA
Current - Output High, Low:	32mA, 32mA
Logic Level - Low:	0.7V ~ 0.8V
Logic Level - High:	1.7V ~ 2V
Max Propagation Delay @ V, Max CL:	3.3ns @ 5V, 50pF
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Supplier Device Package:	8-DSBGA, 8-WCSP (1.9x0.9)
Package / Case:	8-XFBGA, DSBGA
