MC74LCX00DTR2

Part No :: MC74LCX00DTR2

Manufacturer: VIGOR

VIGOR # :: 3814890

Description: IC GATE NAND 4CH 2-INP 14TSSOP

Catalog: Logic - Gates and Inverters

DataSheet: MC74LCX00DTR2 PDF

Country of origin: -

Date code: -

MC74LCX00DTR2 Specifications

Type	Description
Series:	74LCX
Package:	Bulk
Part Status:	Obsolete
Logic Type:	NAND Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	-
Voltage - Supply:	2V ~ 3.6V
Current - Quiescent (Max):	10 µA
Current - Output High, Low:	24mA, 24mA
Logic Level - Low:	0.7V ~ 0.8V
Logic Level - High:	1.7V ~ 2V
Max Propagation Delay @ V, Max CL:	5.5ns @ 3.3V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-TSSOP
Package / Case:	14-TSSOP (0.173", 4.40mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
NLV74LCX32DTR2G Match 100%	VIGOR IC GATE OR 4CH 2-INP 14TSSOP	MC74LCX00DTR2 vs NLV74LCX32DTR2G
MC74LCX00DTR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 4CH 2-INP 14TSSOP	MC74LCX00DTR2 vs MC74LCX00DTR2G
MC74LCX02DTR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NOR 4CH 2-INP 14TSSOP	MC74LCX00DTR2 vs MC74LCX02DTR2G
MC74LCX08DTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE AND 4CH 2-INP 14TSSOP	MC74LCX00DTR2 vs MC74LCX08DTG
SN74LVC02AQPWRQ1 Match 100%	VIGOR SN74LVC02A-Q1 AUTOMOTIVE CATALOG	MC74LCX00DTR2 vs SN74LVC02AQPWRQ1
74LCX32MTC Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 4CH 2-INP 14TSSOP	MC74LCX00DTR2 vs 74LCX32MTC
