SN74AS804BDWG4

Part No :: SN74AS804BDWG4

Manufacturer: Texas Instruments

VIGOR # :: 3814986

Description: IC GATE NAND 6CH 2-INP 20SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN74AS804BDWG4 PDF

Country of origin: -

Date code: -

SN74AS804BDWG4 Specifications

Type	Description
Series:	74AS
Package:	Tube
Part Status:	Not For New Designs
Logic Type:	NAND Gate
Number of Circuits:	6
Number of Inputs:	2
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	-
Current - Output High, Low:	48mA, 48mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	4ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	20-SOIC
Package / Case:	20-SOIC (0.295", 7.50mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
SN74AS804BDW Match 100%	Texas Instruments IC GATE NAND 6CH 2-INP 20SOIC	SN74AS804BDWG4 vs SN74AS804BDW
DM74AS1804WMX Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 6CH 2-INP 20SOIC	SN74AS804BDWG4 vs DM74AS1804WMX
SN74AS804BDWR Match 100%	Texas Instruments IC GATE NAND 6CH 2-INP 20SOIC	SN74AS804BDWG4 vs SN74AS804BDWR
DM74AS804BWM Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 6CH 2-INP 20SOIC	SN74AS804BDWG4 vs DM74AS804BWM
SN74AS804BDWRE4 Match 100%	Texas Instruments IC GATE NAND 6CH 2-INP 20SOIC	SN74AS804BDWG4 vs SN74AS804BDWRE4
SN74AS804BDWRG4 Match 100%	Texas Instruments IC GATE NAND 6CH 2-INP 20SOIC	SN74AS804BDWG4 vs SN74AS804BDWRG4
