MC74VHC1G09DFT1G

MC74VHC1G09DFT1G Specifications

Type	Description
Series:	74VHC
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Logic Type:	AND Gate
Number of Circuits:	1
Number of Inputs:	2
Features:	Open Drain
Voltage - Supply:	2V ~ 5.5V
Current - Quiescent (Max):	1 µA
Current - Output High, Low:	-, 8mA
Logic Level - Low:	0.5V ~ 1.65V
Logic Level - High:	1.5V ~ 3.85V
Max Propagation Delay @ V, Max CL:	7.9ns @ 5V, 50pF
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Supplier Device Package:	SC-88A (SC-70-5/SOT-353)
Package / Case:	5-TSSOP, SC-70-5, SOT-353

Alternative Products

Part Number	Manufacturer & Description	Compare
M74VHC1GT00DFT1G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 1CH 2-INP SC88A	MC74VHC1G09DFT1G vs M74VHC1GT00DFT1G
NLVVHC1GT00DFT2G Match 100%	VIGOR IC GATE NAND 1CH 2-INP SC88A	MC74VHC1G09DFT1G vs NLVVHC1GT00DFT2G
MC74VHC1G09DFT2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE AND OD 1CH 2-INP SC88A	MC74VHC1G09DFT1G vs MC74VHC1G09DFT2G
NLVVHC1G09DFT2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE AND OD 1CH 2-INP SC88A	MC74VHC1G09DFT1G vs NLVVHC1G09DFT2G
M74VHC1GT00DFT2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 1CH 2-INP SC88A	MC74VHC1G09DFT1G vs M74VHC1GT00DFT2G
M74VHC1GT08DFT2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE AND 1CH 2-INP SC88A	MC74VHC1G09DFT1G vs M74VHC1GT08DFT2G
