SN74LS86AD

Part No :: SN74LS86AD

Manufacturer: Texas Instruments

VIGOR # :: 3815900

Description: IC GATE XOR 4CH 2-INP 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN74LS86AD PDF

Country of origin: -

Date code: -

SN74LS86AD Specifications

Type	Description
Series:	74LS
Package:	Tube
Part Status:	Active
Logic Type:	XOR (Exclusive OR)
Number of Circuits:	4
Number of Inputs:	2
Features:	-
Voltage - Supply:	4.75V ~ 5.25V
Current - Quiescent (Max):	10 mA
Current - Output High, Low:	400µA, 8mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	30ns @ 5V, 15pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
SN74LS86ADRE4 Match 100%	Texas Instruments IC GATE XOR 4CH 2-INP 14SOIC	SN74LS86AD vs SN74LS86ADRE4
SN74LS266D Match 100%	Texas Instruments IC GATE XNOR OPEN 4CH 2IN 14SOIC	SN74LS86AD vs SN74LS266D
SN74LS136D Match 100%	VIGOR QUAD 2 INPUT EXCLUSIVE-OR GATES	SN74LS86AD vs SN74LS136D
SN74LS136DR Match 100%	Texas Instruments IC GATE XOR OPEN 4CH 2-IN 14SOIC	SN74LS86AD vs SN74LS136DR
SN74LS266DG4 Match 100%	Texas Instruments IC GATE XNOR OPEN 4CH 2IN 14SOIC	SN74LS86AD vs SN74LS266DG4
SN74LS86ADR Match 100%	Texas Instruments IC GATE XOR 4CH 2-INP 14SOIC	SN74LS86AD vs SN74LS86ADR
