SN74ACT00DBR

Part No :: SN74ACT00DBR

Manufacturer: Texas Instruments

VIGOR # :: 3816025

Description: IC GATE NAND 4CH 2-INP 14SSOP

Catalog: Logic - Gates and Inverters

DataSheet: SN74ACT00DBR PDF

Country of origin: -

Date code: -

SN74ACT00DBR Specifications

Type	Description
Series:	74ACT
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	24mA, 24mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	9ns @ 5V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SSOP
Package / Case:	14-SSOP (0.209", 5.30mm Width)
