SN74HC7002D

Part No :: SN74HC7002D

Manufacturer: Texas Instruments

VIGOR # :: 3816592

Description: IC GATE NOR 4CH 2IN 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN74HC7002D PDF

Country of origin: -

Date code: -

SN74HC7002D Specifications

Type	Description
Series:	74HC
Package:	Tube
Part Status:	Active
Logic Type:	NOR Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	Schmitt Trigger
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	5.2mA, 5.2mA
Logic Level - Low:	0.3V ~ 1.2V
Logic Level - High:	1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL:	22ns @ 6V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
SN74HC7002DG4 Match 100%	Texas Instruments IC GATE NOR 4CH 2IN 14SOIC	SN74HC7002D vs SN74HC7002DG4
SN74HC7001D Match 100%	Texas Instruments IC GATE AND 4CH 2IN 14SOIC	SN74HC7002D vs SN74HC7001D
SN74HC7001DG4 Match 100%	Texas Instruments IC GATE AND 4CH 2IN 14SOIC	SN74HC7002D vs SN74HC7001DG4
SN74HC7032DT Match 100%	Texas Instruments IC GATE OR SCHMIT 4CH 2IN 14SOIC	SN74HC7002D vs SN74HC7032DT
MM74HC30MX Match 100%	VIGOR IC GATE XNOR 4CH 2-INP 14SOIC	SN74HC7002D vs MM74HC30MX
SN74HC7032D Match 100%	Texas Instruments IC GATE OR SCHMIT 4CH 2IN 14SOIC	SN74HC7002D vs SN74HC7032D
