SN74ACT00DG4

Part No :: SN74ACT00DG4

Manufacturer: Texas Instruments

VIGOR # :: 3816944

Description: IC GATE NAND 4CH 2-INP 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN74ACT00DG4 PDF

Country of origin: -

Date code: -

SN74ACT00DG4 Specifications

Type	Description
Series:	74ACT
Package:	Tube
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	24mA, 24mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	9ns @ 5V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
74ACT32SC Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 4CH 2-INP 14SOIC	SN74ACT00DG4 vs 74ACT32SC
MC74ACT32DG Match 100%	VIGOR OR GATE, ACT SERIES, 4-FUNC, 2-I	SN74ACT00DG4 vs MC74ACT32DG
74ACT00SC Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 4CH 2-INP 14SOIC	SN74ACT00DG4 vs 74ACT00SC
SN74ACT08DE4 Match 100%	VIGOR IC GATE AND 4CH 2-INP 14SOIC	SN74ACT00DG4 vs SN74ACT08DE4
74ACT32SCX Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 4CH 2-INP 14SOIC	SN74ACT00DG4 vs 74ACT32SCX
SN74AHCT132D Match 100%	Texas Instruments IC GATE NAND 4CH 2-INP 14SOIC	SN74ACT00DG4 vs SN74AHCT132D
