SN74LS136N

Part No :: SN74LS136N

Manufacturer: Texas Instruments

VIGOR # :: 3817812

Description: IC GATE XOR OP COL 4CH 2IN 14DIP

Catalog: Logic - Gates and Inverters

DataSheet: SN74LS136N PDF

Country of origin: -

Date code: -

SN74LS136N Specifications

Type	Description
Series:	74LS
Package:	Tube
Part Status:	Active
Logic Type:	XOR (Exclusive OR)
Number of Circuits:	4
Number of Inputs:	2
Features:	Open Collector
Voltage - Supply:	4.75V ~ 5.25V
Current - Quiescent (Max):	10 mA
Current - Output High, Low:	-, 8mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	30ns @ 5V, 15pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Through Hole
Supplier Device Package:	14-PDIP
Package / Case:	14-DIP (0.300", 7.62mm)
