SN74AS20N

Part No :: SN74AS20N

Manufacturer: Texas Instruments

VIGOR # :: 3818529

Description: IC GATE NAND 2CH 4-INP 14DIP

Catalog: Logic - Gates and Inverters

DataSheet: SN74AS20N PDF

Country of origin: -

Date code: -

SN74AS20N Specifications

Type	Description
Series:	74AS
Package:	Tube
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	-
Current - Output High, Low:	2mA, 20mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	5ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Through Hole
Supplier Device Package:	14-PDIP
Package / Case:	14-DIP (0.300", 7.62mm)

Alternative Products

Part Number	Manufacturer & Description	Compare
SN74S20NG4 Match 100%	Texas Instruments IC GATE NAND 2CH 4-INP 14DIP	SN74AS20N vs SN74S20NG4
SN74S20N Match 100%	Texas Instruments IC GATE NAND 2CH 4-INP 14DIP	SN74AS20N vs SN74S20N
74F20PC Match 100%	VIGOR IC GATE NAND 2CH 4-INP 14DIP	SN74AS20N vs 74F20PC
74F40PC Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 2CH 4-INP 14DIP	SN74AS20N vs 74F40PC
