MC74AC20NG

Part No :: MC74AC20NG

Manufacturer: VIGOR

VIGOR # :: 3818691

Description: IC GATE NAND 2CH 4-INP 14DIP

Catalog: Logic - Gates and Inverters

DataSheet: MC74AC20NG PDF

Country of origin: -

Date code: -

MC74AC20NG Specifications

Type	Description
Series:	74AC
Package:	Tube
Part Status:	Obsolete
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Max):	4 µA
Current - Output High, Low:	24mA, 24mA
Logic Level - Low:	0.9V ~ 1.65V
Logic Level - High:	2.1V ~ 3.85V
Max Propagation Delay @ V, Max CL:	7ns @ 5V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Through Hole
Supplier Device Package:	14-PDIP
Package / Case:	14-DIP (0.300", 7.62mm)
