MC14023BDR2G

Part No :: MC14023BDR2G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3820023

Description: IC GATE NAND 3CH 3-INP 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: MC14023BDR2G PDF

Country of origin: -

Date code: -

MC14023BDR2G Specifications

Type	Description
Series:	4000B
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	3
Number of Inputs:	3
Features:	-
Voltage - Supply:	3V ~ 18V
Current - Quiescent (Max):	1 µA
Current - Output High, Low:	8.8mA, 8.8mA
Logic Level - Low:	1.5V ~ 4V
Logic Level - High:	3.5V ~ 11V
Max Propagation Delay @ V, Max CL:	100ns @ 15V, 50pF
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)
