MC14093BDG

Part No :: MC14093BDG

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3820629

Description: IC GATE NAND 4CH 2-INP 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: MC14093BDG PDF

Country of origin: -

Date code: -

MC14093BDG Specifications

Type	Description
Series:	4000B
Package:	Tube
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	Schmitt Trigger
Voltage - Supply:	3V ~ 18V
Current - Quiescent (Max):	1 µA
Current - Output High, Low:	8.8mA, 8.8mA
Logic Level - Low:	0.9V ~ 4V
Logic Level - High:	3.6V ~ 10.8V
Max Propagation Delay @ V, Max CL:	80ns @ 15V, 50pF
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)
