SN7414D

Part No :: SN7414D

Manufacturer: Texas Instruments

VIGOR # :: 3821446

Description: IC INVERT SCHMITT 6CH 6IN 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN7414D PDF

Country of origin: -

Date code: -

SN7414D Specifications

Type	Description
Series:	7400
Package:	Tube
Part Status:	Active
Logic Type:	Inverter
Number of Circuits:	6
Number of Inputs:	6
Features:	Schmitt Trigger
Voltage - Supply:	4.75V ~ 5.25V
Current - Quiescent (Max):	-
Current - Output High, Low:	800µA, 16mA
Logic Level - Low:	0.6V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	22ns @ 5V, 15pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)
