SN74F20D

Part No :: SN74F20D

Manufacturer: Texas Instruments

VIGOR # :: 3821750

Description: IC GATE NAND 2CH 4-INP 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN74F20D PDF

Country of origin: -

Date code: -

SN74F20D Specifications

Type	Description
Series:	74F
Package:	Tube
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	-
Current - Output High, Low:	1mA, 20mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	6ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
SN74AS21DR Match 100%	VIGOR IC GATE AND 2CH 4-INP 14SOIC	SN74F20D vs SN74AS21DR
SN74AS21D Match 100%	Texas Instruments IC GATE AND 2CH 4-INP 14SOIC	SN74F20D vs SN74AS21D
DM74AS21M Match 100%	VIGOR IC GATE AND 2CH 4-INP 14SOIC	SN74F20D vs DM74AS21M
SN74F20DRE4 Match 100%	Texas Instruments IC GATE NAND 2CH 4-INP 14SOIC	SN74F20D vs SN74F20DRE4
SN74F20DR Match 100%	Texas Instruments IC GATE NAND 2CH 4-INP 14SOIC	SN74F20D vs SN74F20DR
DM74AS21MX Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE AND 2CH 4-INP 14SOIC	SN74F20D vs DM74AS21MX
