SN74HC7002NG4

Part No :: SN74HC7002NG4

Manufacturer: Texas Instruments

VIGOR # :: 3821799

Description: IC GATE NOR SCHMIT 4CH 2IN 14DIP

Catalog: Logic - Gates and Inverters

DataSheet: SN74HC7002NG4 PDF

Country of origin: -

Date code: -

SN74HC7002NG4 Specifications

Type	Description
Series:	74HC
Package:	Tube
Part Status:	Active
Logic Type:	NOR Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	Schmitt Trigger
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	5.2mA, 5.2mA
Logic Level - Low:	0.3V ~ 1.2V
Logic Level - High:	1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL:	22ns @ 6V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Through Hole
Supplier Device Package:	14-PDIP
Package / Case:	14-DIP (0.300", 7.62mm)
